SigenStor Retrofit: Intelligent Energy Management for Optimal Efficiency
Sigenergy
recently addressed a factory's longstanding power distribution challenges with
its innovative SigenStor energy storage solution.
“The Sigenergy solution exceeded my expectations,” shared
the project leader at Fuguang Environment (Guangdong) Co., Ltd., following
their use of Sigenergy’s system. “It not only met our energy needs while
maximizing solar power use, but it also eliminated many complex operational
tasks.”
The
factory previously struggled with frequent tripping of its main switch during
peak production periods. Although a PV system was installed to offset the load,
power interruptions continued on cloudy days and during periods of low
sunlight. To remedy this, the factory installed a 215 kWh energy storage
system. However, this system was limited to scheduled charging and discharging,
without integration with the PV system. As a result, the PV inverter limited or
even stopped solar output during storage discharges due to anti-reverse flow
controls.
Fuguang
Environment ultimately chose SigenStor to replace the initial setup,
successfully enhancing both power stability and production efficiency.
The
project utilized Sigenergy's 50kW/96kWh solution, seamlessly integrating solar
generation and energy storage, and providing the factory with several key
advantages:
Quick
Installation and Stable Operation
SigenStor
features an embedded EMS, removing the need for external data logger, and
employs industry-leading full-network communication technology. This setup
accelerates communication speeds and response times by over tenfold, supporting
device self-recognition and auto-networking. Installation and setup are
completed in less than half a day, saving both time and costs. Additionally,
the system offers an extended 500-meter Arc Fault Circuit Interrupter (AFCI)
range for enhanced safety and stability.
Dynamic
Real-Time Adjustment
The
SigenStor system dynamically allocates power based on factory load variations,
maximizing self-consumption. During sunny periods, solar power supplies the
factory, with excess energy stored in the battery for optimal green energy
utilization. On cloudy days or at night, the storage system supplies power from
the battery to ensure continuous operation. When battery power is low, the
system seamlessly switches to grid power, balancing solar generation with load
demand to prevent production interruptions.
Dynamic
Capacity Expansion for Peak Loads
The
system features intelligent load detection, allowing the factory to set custom
load limits. When the load exceeds these limits, the system automatically
boosts the energy storage’s output to prevent tripping. When the load is below
the threshold, the system prioritizes grid power, extending the lifespan of the
storage unit.
User-Friendly
Operation and Efficient Maintenance
Unlike
traditional storage solutions, SigenStor provides flexible, customizable
settings for easy adjustment and management. Integrated with the latest AI
technology, the mySigen App offers personalized voice support and natural
language interaction, delivering precise energy recommendations, optimization
insights, quick setup, and in-depth query capabilities. The system also
includes automated diagnostics and remote inspections, allowing management to
monitor energy usage and manage power distribution directly from a mobile
device.
Exceptional
Scalability
With
its modular design, SigenStor can be scaled in 8kWh increments to meet specific
capacity requirements. The system supports the use of new and existing
batteries together, allowing rapid, adaptable installation.
Since
implementing SigenStor, the factory has achieved a green, efficient, and
sustainable production model, significantly improving power reliability and
cost-efficiency. Sigenergy remains committed to providing commercial and
industrial clients with green, efficient, and flexible energy management
solutions, leveraging advanced technology and intelligent applications to
support a low-carbon, sustainable future.
